A-i single stage Series
A-i120、A-i140、A-i160、A-i180
Quantity:
Technical Parameter
| Models | A-i120 | A-i140 | A-i160 | A-i180 | |
| Flow Rate | 50Hz | 1.8CFM | 3.5CFM | 5.0CFM | 7.0CFM |
| 51L/min | 100L/min | 142L/min | 198L/min | ||
| 60Hz | 2.0CFM | 4.0CFM | 6.0CFM | 8.0CFM | |
| 57L/min | 113L/min | 170L/min | 227L/min | ||
| Ultimate Vacuum | Partial Pressure | 2Pa | 2Pa | 2Pa | 2Pa |
| Total pressure | 150mircons | 150mircons | 150mircons | 150mircons | |
| Power | 1/3HP | 1/2HP | 1/2HP | 3/4HP | |
| Inlet Port | 1/4"SAE | 1/4"& 3/8"SAE | 1/4"& 3/8"SAE | 1/4"& 3/8"SAE | |
| Oil Capacity | 230ml | 230ml | 350ml | 320ml | |
| Dimensions (mm) | 240x93x200 | 320x125x232 | 340x132x245 | 360x132x245 | |
| Weight | 5.0kg | 8kg | 11.0kg | 13.5kg | |
